XKZ-20G2电控箱 出口用给料机调速器 （英文面板）

XKZ-20G2电控箱 出口用给料机调速器 （英文面板）是针对出口而设计的电磁振动给料机电控箱调速控制系统，其面板采用中英文结合使外国客户简单易懂，该电控箱电流范围值为10.6A，输入电压两项220V。电磁振动给料机电气控制采用半波整流电路，可无级调节给料量，可用于自动控制的生产流程中，实现生产过程自动化。

Xkz-20g2 electric control box export feeder governor (English panel) is designed for the export of electromagnetic vibration feeder electrical control box speed control system, its panel uses the combination of Chinese and English, so that foreign customers can easily understand, the electric box current range is 10.6a, the input voltage of two items of 220 v. The electric control of electromagnetic vibration feeder adopts half wave rectifying circuit, which can adjust the feeding amount steplessly, and can be used in the production process of automatic control to realize the automation of production process.

电磁振动给料机又叫定量给料机。主要用于把物料从贮料仓或其它贮料设备中均匀或定量的供给到受料设备中，是实行流水作业自动化的必备设备分敞开型和封闭 型两种.根据安装方式可分悬挂式和台式等两种。电磁振动给料机结构简单，操作方便，不需润滑，耗电量小;可以均匀地调节给矿量，因此已得到广泛应用。特别 适合雷蒙磨粉机和球磨机的给料配套。

, it can be divided into suspension type and table type. Electromagnetic vibration feeder has the advantages of simple structure, convenient operation, no need of lubrication and low power consumption; it can adjust the ore feeding amount evenly,

Advantages of electromagnetic vibration feeder:

1. The electric control of electromagnetic vibration feeder adopts half wave rectification circuit, which can adjust the feeding amount steplessly, and can be used in the production process of automatic control to realize the automation of production process.

2. No rotating parts, no lubrication, simple structure and convenient maintenance.

3. The material of electromagnetic vibration feeder is slightly thrown, and the wear of material groove is small.

4. The electromagnetic vibration feeder can adopt the material trough made of integral plate, which can be used to transport materials with serious abrasion and corrosivity at high temperature.

Overall dimension: 180 × 162 × 254 (mm);

Shell protection grade: IP65;

Short circuit making current: 25 (KA);

Rated voltage: 220 (V)

Rated current: 20 (a);

Model: xkz20g2 electric control box;

Brand: St. rete;

Xkz series electric control box for electromagnetic feeder controller of feeder speed governor is a kind of electromagnetic feeding machine supplied by Saint rete machinery, Xkz series electric control box is also called feeder governor, which uses thyristor trigger device to control the electromagnetic coil. According to the conventional use models, there are 20a and 5A, namely xkz-5g2 electric control box and xkz-20g2 electric control box. For electromagnetic feeders above 6, three-phase feeding control box and xkz-20g3 electric control box are selected.

1、 Features of xkz series electric control box:

2. The thyristor works with pulse phase-shifting trigger, which can effectively control the sudden change of current and voltage, make the load start smoothly, and ensure the safe use of thyristor.

, which can be hung or placed horizontally, providing convenience for the installation and operation of the machine.

2、 How to use xkz series electric control box:

2. Turn on the power on key, the working indicator light is on, indicating that the power is connected.

3、 Precautions for xkz series electric control box:

, it is generally not necessary to short circuit the load artificially.

2. The medium temperature around the electronic controller should not exceed the range of - 20 ℃ - + 40 ℃.

3. When the temperature of surrounding medium is 25 ℃, the relative humidity is not more than 85%.

4. The electric controller should be placed in the environment with small vibration amplitude, no serious corrosive gas and influence on electrical insulation performance.

4、 Main performance indicators

1. Input and output voltage ＜ 10V (measured when input voltage is greater than or equal to 220V) 5V 〉.

2. It is suitable for positive and negative 220 V ± 15% variation.

!
